FJC-Z2358GB Swing Gate
FJC-Z2358GB
The FJC-Z2358GB intelligent swing gate uses the brushless DC motor and servo control technology, which is characterized with good synchronism, stable operation, and a low failure rate. In addition, the product is designed as a module as a whole, and has diversified gate opening manners expanded to face recognition, card swiping, QR code, and ID card, etc. With a simpler structure and easier maintenance, the product is widely applied to different indoor and outdoor sites such as airports, office buildings, factories, railway stations, customs, and docks.
- Introduction
- Specifications
- Accessories
- Download
-
Stable and Efficient Motor
Brushless DC motor, strong power, integrated core design, wear resistance and noise reduction, and stability and efficiency.
Diversified Access Permissions
Diversified access permissions, and expandable to face recognition, IC card swiping, QR code, and ID card swiping, etc.
Intelligent Security Protection
Multiple intelligent anti-pinch technologies, as well as the partition detection and fuzzy algorithm, to effectively protect pedestrians.
Automatic Management Functions
Integrate automatic reset, unlocking when being powered off, self-check when being powered on, zero point correction, etc.
-
Product Model
FJC-Z2358GB
Body And Side Frame Material
304 stainless steel
Gate Material
Tempered glass or acrylic
Top Cover Material
304 stainless steel
Color
Stainless steel original color
Dimension (L*W*H)
1，600*116*950mm
Lane Width
600-1，150mm
Gate Interception Height
800mm
Gate Height From The Ground
240mm
Motor
DC brushless motor
Power Supply
AC 220V/110V±10%， 50/60HZ
Device Power
Total power: 100W， motor power: 40W
Passing Speed
Normally closed: 20 persons/minute
Normally opened: 40 persons/minute
Open-closing Speed
0.5s-1.5s adjustable
Detection Method
Photoelectric switch
Number of Electric Eyes
10 Pairs
Communication Interface
Serial port and multi-channel I/O interface
Communication
RS485 and TCP/IP
Noise
≤65dB
Working Temperature
-25℃ to +70℃
Working Humidity
≤90%， no condensation
Protection Class
IP54
Working Environment
Indoor and outdoor
FJC-Z358GB Swing Gate Datasheet
8.1MB
